- Perlindungan panas berlebih: Otomatis mematikan pemanas dengan indikasi suara dan visual ketika autoklaf terlalu panas.
- Perlindungan anti-pembakaran: Otomatis mematikan pemanas dengan indikasi suara dan visual ketika autoklaf kekurangan air.
- Pengaman interlock: Mencegah siklus dimulai jika pintu tidak tertutup rapat atau pintu terbuka jika terdapat tekanan di dalam ruang.
- Katup pengaman tekanan uap: Otomatis bekerja ketika tekanan ruang melebihi batas.
- Pengoperasian sterilisasi otomatis dengan kontrol mikroprosesor PID dan layar LCD.
- Fungsi pulsa positif menghilangkan udara secara efisien.
- Program cairan dengan kontrol tekanan otomatis mencegah cairan meluap dan meledaknya botol atau kantong.
- Dilengkapi fungsi memori mati daya.
- Tangki air internal dengan sirkulasi internal uap-air.
Spesifikasi :
| Model | ST-V50A | ST-V80A | ST-V100A | ST-V120A | ST-V150A |
| Capacity | 50L | 80L | 100L | 120L | 150L |
| External Size (WxDxH)(mm) | 476x616x990 | 546x688x1030 | 566x708x1295 | 620x760x1190 | 680x820x1180 |
| Chamber Size (ØxH)(mm) | Ø316×667 | Ø386×695 | Ø400×800 | Ø450×760 | Ø500×780 |
| Chamber Material | SUS304 | ||||
| Sterilization Temperature | 105~136 ℃ | ||||
| Designed Temperature | 150℃ | ||||
| Max.Working Temperature | 136 ℃ | ||||
| Dissolution Temperature | 40~100℃ | ||||
| Warming Temperature | 40~60℃ | ||||
| Temp.Accuracy | 0.1℃ | ||||
| Designed Pressure | 0.3Mpa | ||||
| Max.Sterilization Pressure | 0.23Mpa | ||||
| Sterilization Time Range | 0~99min | ||||
| Display | LCD touch screen | ||||
| Drying Function | YES | ||||
| Drying Time | 15min | ||||
| Sterilization Program | ●Dressings/Fabric program
●Tools program ●Rubber program ●Culture medium sterilization warming program ●Culture medium dissolution warming program ●Liquids in closed containers (glass bottle, plastic bottle and bag) program ●Waste program |
||||
| Water Injection Method | Built-in water tank | ||||
| Power Consumption | 3KW | 4.5KW | 5.4KW | 5.4KW | 9.3KW |
| Power Supply | 220V 50Hz | 220V 50Hz | 220V 50Hz | 380V 50Hz | 380V 50Hz |
| Standard SS Basket | 2pcs | 2pcs | 2pcs | 2pcs | 2pcs |
| Net Weight | 68kg | 92kg | 100kg | 175kg | 195kg |
| Gross Weight | 103kg | 127kg | 140kg | 215kg | 235kg |
| Shipping Size (WxDxH)(mm) | 730x820x1250 | 800x880x1300 | 800x880x1480 | 950x1050x1280 | 950x1050x1440 |
