Lab/Medical Refrigerator Specifications:
| Model | MR-5V250 | MR-5V310 | MR-5V320 | MR-5V315 | MR-5V415 | MR-5V420 | ||
|---|---|---|---|---|---|---|---|---|
| Capacity (L) | 226 | 312 | 316 | 316 | 416 | 416 | ||
| Size(WxDxH)(mm) | Internal | 534x406x1150 | 560x485x1350 | 540x425x1380 | 540x425x1380 | 685x429x1380 | 685x429x1380 | |
| External | 625x594x1707 | 650x624x1902 | 660x555x1915 | 640×554×1925 | 785×552×1927 | 785×552×1927 | ||
| Temperature | Range (℃) at RT.10~32℃ | 2~8 (Optional 2~10; 2~14) | 2~8 (Optional 2~10; 2~14) | 2~8 (Optional 2~10; 2~14) | 2~8 (Optional 2~10; 2~14) | 2~8 (Optional 2~10; 2~14) | 2~8 (Optional 2~10; 2~14) | |
| Sensor | NTC | NTC | NTC | NTC | NTC | NTC | ||
| Controller | Microprocessor | Microprocessor | Microprocessor | Microprocessor | Microprocessor | Microprocessor | ||
| Cooling System | Refrigerant | R600a (CFC Free) | R290 (CFC Free) | R290 (CFC Free) | R290 (CFC Free) | R290 (CFC Free) | R290 (CFC Free) | |
| Defrost | Auto | Auto | Auto | Auto | Auto | Auto | ||
| China Compressor (Qty) |
1 | 1 | 1 | 1 | 1 | 1 | ||
| Display | Digital display | Digital display | Digital display | Digital display | Digital display | Digital display | ||
| Audible & Visible Alarm | Standard | High/Low temperature, door ajar | ||||||
| Power Failure Backup System (Alarm) | 8h | 8h | 8h | 72h | 72h | 8h | ||
| Material | Internal | Blister liner | Blister liner | Electro-galvanized steel with antimicrobial powder
coating |
Electro-galvanized steel with antimicrobial powder
coating |
Electro-galvanized steel with antimicrobial powder
coating |
Electro-
galvanized steel with antimicrobial powder coating |
|
| External | Electro-galvanized steel with antimicrobial powder coating | |||||||
| Accessories | USB Port | Optional | / | Optional | Standard | Standard | Optional | |
| Casters | Standard | Standard | Standard | Standard | Standard | Standard | ||
| Chart Recorder | / | / | / | / | / | / | ||
| Data Logger | Optional | Optional | Optional | Optional | Optional | Optional | ||
| Remote Alarm Port | Standard | Standard | Standard | Standard | Standard | Standard | ||
| Test Hole (Qty) / φ (mm) | 1/25 | 1/25 | 1/25 | 1/25 | 1/25 | 1/25 | ||
| Shelves / Drawers (Qty) | Shelves/4 | Shelves/5 | Shelves/5 | Shelves/6, Basket/1 | Shelves/6, Basket/1 | Shelves/5 | ||
| Sound Emission (dB) | 50 | 50 | 50 | 50 | 50 | 50 | ||
| Electricity | Voltage/Frequency | AC110/220V±10%, 50/60Hz | ||||||
| Consumption (W) | 140 | 245 | 240 | 294 | 330 | 280 | ||
| N.W./G.W. (Kg) | 73/76 | 86/90 | 92.5/100 | 92.5/100 | 120/133 | 120/133 | ||
| Shipping Size (WxDxH) (mm) | 707x676x1745 | 710x680x1960 | 710x680x1960 | 710x680x1960 | 854x646x2100 | 890x655x2100 | ||
Fitur Laboratory Refrigerator :
- Sistem pendingin udara paksa dengan kompensasi panas elektrik yang dikontrol oleh mikroprosesor.
- Sistem defrost otomatis memastikan tidak ada kelembapan pada permukaan pendingin.
- Pintu kaca berlapis ganda dengan desain Hollow Insulation (MR-5V100).
- Layar LED bening dan panel kontrol mendukung tampilan dan pengoperasian yang mudah.
- Kaki yang rata untuk pemasangan yang mudah.
Sistem Unggulan :
- Pintu yang dapat dikunci dan pengaturan parameter mikroprosesor yang dilindungi kata sandi.
- Baterai cadangan internal hingga 8 jam untuk menampilkan suhu dan mengoperasikan sistem alarm suara dan visual.
- Monitor pintu bagian dalam untuk menyalakan/mematikan kipas pendingin guna mencegah udara dingin bocor keluar.
- Buzzer yang dapat didengar dan sistem alarm suhu yang berkedip-kedip untuk suhu tinggi/rendah, kegagalan daya, tegangan abnormal, pintu terbuka, baterai cadangan.
- Pintu akrilik bagian dalam yang terpisah memastikan lebih sedikit gangguan pada setiap ruang saat pintu lainnya dibuka.
